Radiomasters Bandit Micro ExpressLRS 915MHz RF Module

€64.00

Not available

Veikt rezervāciju

That you for messaging!

Your message was sent successfully. Our employees will contact you shortly.

Ask a question

Specification:

Manufacturer: radiomaster
Produkta tips: FPV Dronu aksesuāri

Features

Up to 1 Watt power output
Packet rates up to 200Hz
Optimized circuitry for ultra-low power consumption
Built-in TCXO oscillator
Low noise, high comfort
High contrast OLED display
Innovative convection cooling design
Wifi and Bluetooth support
Built-in ExpressLRS backpack
5 Directional nav key
915/868MHz T Antenna included
With the Micro connector, support TX16S MKII, Boxer, and TX12 MKII radio

Specifications

Item: Bandit Micro ExpressLRS RF Module
Regulatory Domain: FCC915
MCU: ESP32(main), ESP8285(aux, as ESP backpack)
RF Chip: SEMTECH SX1276
Refresh Rate Min/Max: 25Hz/200Hz
RF Output Power: 1000mW/30dBm
Micro standard 5pin connector
Built-in OLED screen
XT30 Power Supply Voltage: DC 6V ~ 16.8V
Weight: 78.0grams (with T antenna)
Dimension: 64.1*49.6*34.1mm

Keep Your Cool!

With its innovative convection cooling system and built-in turbo fan, the Bandit Micro ExpressLRS module ensures optimal temperature control and operates with minimal noise. The Bandit Micro form factor is ready to go with our TX16S MKII, Boxer, TX12 MKII and other radios with a Micro Module bay.

Intuitive Control at Your Fingertips

The Bandit Micro ExpressLRS features an OLED display, a five-directional navigation key, ensuring an unparalleled flying experience.

Versatile Antenna Options for Diverse Applications

The Bandit Micro ExpressLRS comes equipped with a RadioMaster T Antenna for general-purpose flying. The RadioMaster Moxon antenna is available separately for long-range directional applications. This versatility empowers you to adapt your setup to suit any flying scenario, from everyday recreational flights to professional drone and UAV operations.

The Ideal Solution for Demanding Applications

Whether you're an experienced drone enthusiast or a professional UAV operator, the Bandit Micro ExpressLRS RF Module is the perfect choice for your demanding applications. Its unmatched performance, rugged construction, intuitive controls, and versatile antenna options make it an indispensable tool for those seeking the very best in long-range drone and UAV technology.
